TX-SR494

7.2-Channel AV Receiver

From easy Bluetooth^® wireless streaming to the heart-pounding thrills of Dolby Atmos^® and DTS: X^® soundtracks, the TX-SR494 A/V receiver delivers outstanding sound.

Seven channels of high-current power give you the freedom to choose a speaker layout that suits you.

Ready for 4K Entertainment

Enjoy support for HDR (High Dynamic Range) video including HDR10, HLG, Dolby Vision^®, and BT.2020. The 4:4:4 color space is also supported. Six HDMI inputs, ARC-ready MAIN OUT, and SUB OUT pass 4K/60p and HDR video from player to compatible TV and projector and all terminals are HDCP 2.2 compliant.

Smooth and Easy Bluetooth Streaming

Whatever audio is playing on your phone, tablet, or PC app can be streamed to the receiver with Bluetooth wireless technology. Once the receiver has paired with and remembered your device, it will start playback automatically whenever it detects an incoming Bluetooth audio stream.

Dolby Atmos® and DTS:X® – Setting Sound Free

Dolby Atmos^® and DTS:X^® formats allow engineers to map sound anywhere in 3D space, effects moving from speaker to speaker all around the room and wrapping your audience in the latest films and games. You can also enjoy your 3D speaker layout with classic titles. Dolby Surround^® and DTS^® Neural:X find overhead cues in legacy soundtracks and upmix for awesome spatial realism.

Dolby Atmos Height Virtualizer

When playing any Dolby^® format, engaging Dolby Atmos Height Virtualizer enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without employing additional surround or height speakers.

Looking for more? Check out these similar products

TX-RZ1100 9.2-Channel Network AV Receiver

TX-NR696 7.2-Channel Network AV Receiver

TX-SR393 5.2-Channel AV Receiver

Features

Amplifier

# Channels	7.2
Power Watts/Ch (8 Ohms 20-20kHz, 2 Channels Driven, FTC)	80 Watts, 0.08% THD
Power Watts/Ch (6 Ohms 1kHz, 1 Channel Driven, FTC)	160 Watts, 10% THD
Dynamic Audio Amplification	-
H.C.P.S. (High Current Power Supply)	✓
Non-Phase Shift Amplifier	-
THX Certified	-
Certified 4 Ohms Performance	✓
Discrete Output Stage Circuitry	✓
Amplifier Design	-
Independent Block Construction (Amp/Preprocessor)	-
Bi-amp Capability For Front	✓

Processing

Dolby Atmos	✓(5.2.2)
32-Bit Digital Signal Processing Engine	✓
Dolby Atmos Height Virtualizer	✓
Dolby Surround® upmixing	✓
Dolby Decoder	Dolby Atmos, Dolby True HD
DTS:X	✓(5.2.2)
DTS Virtual:X	✓
DTS Neural:X upmixing	✓
DTS Decoder	DTS:X, DTS-HD Master Audio
Dolby® Pro Logic IIz upmixing for stereo and multichannel soundtracks	-
ONKYO GAME Surround Modes	-
VLSC for Noiseless Audio Processing	-
THX Processing Mode	-
CinemaFILTER	✓
AccuEQ Room Calibration	✓(w/ AccuReflex)
Phase-Matching Bass Boost	-
Direct/Pure Mode	✓/-
Pure Direct Analog Path Mode	-
Advanced Music Optimizer	✓
384K/32 Bit DACs	✓
192K/24 Bit DACs	-

Connectivity

Analog Audio IN	3
Phono Input	-
Digital Audio IN (OPT/COAX)	1 / 1
Composite Video I/O	-
Component Video I/O	-
Front Panel HDMI	-
Front-Panel A/V	-
USB Input	✓
HDMI I/O	4 / 1
HDMI 4K/60 Hz- Capable HDMI Terminals	✓
HDCP 2.3 Copy-Protection Compatibility	✓
HDMI Support for High Dynamic Range	✓
HDMI Support for 3D, Audio Return Channel and CEC	✓
BT.2020 Support	✓
HDMI Support for Deep Color, x.v.Color, LipSync	✓
HDMI Support for DVD-Audio, SACD, Multichannel PCM	✓
Analog To HDMI Upconversion	-
1080p to 4K Upscaling	✓
4K Passthrough	✓
Analog Pre-Outs	Dual Subwoofer
Speaker A/+B	-
Powered Zone 2	-
Powered Zone 3	-
Zone B Line Out	✓
Zone 2 Line Out	-
Zone 2 Video Out	-
Zone 2 Digital to Analog Audio Conversion	-
Zone 3 Line Out	-
Whole House Mode	-
FlareConnect Multi-room Audio	-
Airplay	-
Google Cast	-
Supports Onkyo Remote App	-
Internet Radio Capable	-
Spotify Connect Support	-
Tidal	-
Streaming Audio From PC / Network	-
Hi-Res Streaming Audio Formats	-
Streaming Audio From USB memory	-
Wireless Network	-
Bluetooth	✓

Integration Access

RS-232	-
IR Input	-
IR Output	-
Ethernet	-
ONKYO-RI System Control	-
RIHD (Remote Interactive Over HDMI)	-
12V Trigger	-

Miscellaneous

Pre-Pro/Learning Remote	-/-
On Screen Remote Programming	-
Hybrid Standby Function	-
Smart Grid-Ready	-
Auto Speaker Calibration W/Mic.	AccuEQ
OSD Out	✓
Solid Aluminum Front	-
Transparent High-Grade Speaker Terminals	-
Detachable AC Cord	-
Warranty	2 YEARS

Specs

Amplifier Section

All Channels	80 W/Ch (8 Ohms, 20 Hz–20 kHz, 0.08% THD, 2 Channels Driven, FTC) 160 W/Ch (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)
THD+N (Total Harmonic Distortion + Noise)	0.08% (20 Hz–20 kHz, 8 Ohms, 1 Channel Driven, 80 W)
Input Sensitivity and Impedance	200 mV / 47k Ohms (Line)
Frequency Response	10 Hz–100 kHz /+ 1 dB, -3 dB (Direct Mode)
Tone Control	±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio	109 dB (Line, IHF-A)
Speaker Impedance	4 ohms–16 ohms

Video Section

Video	1.0 Vp–p ±5% / 75 Ohms (Composite)

Tuner Section

FM	87.5 MHz–107.9 MHz
AM	530 kHz–1,710 kHz
FM/AM Preset Memory	40 stations

General

Power Supply	AC 120 V~, 60 Hz
Power Consumption	490 W
Standby Power Consumption	0.1 W
Dimensions (W x H x D)	17 1/8" x 6 5/8" x 12 15/16" (435 x 160 x 328 mm)
Weight	18.1 lbs (8.2 kg)

Carton

Dimensions (W x H x D)	20 11/16" x 9 7/16" x 15 15/16" (525 x 240 x 405 mm)
Weight	23.1 lbs. (10.5 kg)

UPC Code

(B)	889951002871
